30-pin to USB Cable (1 m, 2012)

Apple’s 30-pin to USB Cable was sold in a variety of packaging options over the years. This cable charged devices with a 30-pin connector, including iPod, iPhone, and iPad.

Apple’s product overview stated, “This USB 2.0 cable connects your iPod, iPhone, or iPad — directly or through a Dock — to your computer’s USB port for efficient syncing and charging or to the Apple USB Power Adapter for convenient charging from a wall outlet.”

Apple also included a list of compatible devices. Although the USB 2.0 is backwards-compatible with USB 1.0 and works with computers with USB 3.0, the specifications only include devices that use USB 2.0: iPhone 4s, iPhone 4, iPhone 3Gs, iPhone 3G, iPod touch (4th generation), iPod touch (3rd generation), iPod touch (2nd generation), iPod nano (6th generation), iPod nano (5th generation), iPod nano (4th generation), iPod classic 160GB (2009), and iPod classic 120GB (2008).

This example is unopened in retail packaging. Although Apple was no longer selling devices with 30-pin cables, this product was still available on Apple’s website as of January 2021.

Source: Apple

Posted on

Apple Watch Magnetic Charging Dock (2015)

The Apple Watch Magnetic Charging Dock was a 4.1-inch diameter, 0.5-inch thick charging pad for the Apple Watch that used the same inductive charging connector that shipped with the Apple Watch. The white base of the dock had a microfiber, padded texture. The polished-chrome charging disc was mounted on a hinge that could pivot from a flat position to a 45-degree angle.

According to Apple:

“With the Apple Watch Magnetic Charging Dock, you can charge your Apple Watch in a flat position with its band open, or on its side. When docked on its side, your watch automatically goes into Nightstand mode, so you can also use it as your alarm clock. The Apple Watch Magnetic Charging Dock uses the same inductive charging connector that comes with Apple Watch. It charges all Apple Watch models and sizes. And it connects via the Lightning to USB Cable and Apple 5W USB Power Adapter.”

The Apple Watch Magnetic Charging Dock has also shipped with Apple Watch Edition models and has been available since 2015 with a Lightning connector built into the base. As of 2020 it still shipped with a Lightning-to-USB (USB-A) cable.

This example is the standalone product with the original packaging.

Source: Apple

Posted on

Lightning to USB Cable (1 m, 2015)

Apple has sold and included their Lightning to USB Cable in various formats and packaging options over the years. This version of the product and packaging is part number ZM826-0420-B. Apple specifies that the Lightning to USB Cable is “Compatible with all models with a Lightning connector.”

Posted on

Apple Watch Magnetic Charging Cable (1 m, 2019)

The original Apple Watch Magnetic Charging Cable was available in two versions, a white plastic back and a steel back. The Magnetic Charging Cable that shipped with aluminum Apple Watch models had the white plastic back, and Magnetic Charging Cables included with Stainless Steel and Edition models had the steel back. When purchased separately, the Magnetic Charging Cable used the steel back.

This 1-meter version of the Apple Watch Magnetic Charging Cable has a USB-A plug. A version is also available with a USB-C plug, referred to on Apple’s website as an Apple Watch Magnetic Charger to USB-C Cable. These cables were available in three lengths, 0.3 m, 1 m, and 2 m.

Although not an official “MagSafe” product, Apple refers to MageSafe technology in the description:

“We wanted to make charging your Apple Watch utterly effortless. So we arrived at a solution that combines our MagSafe technology with inductive charging. It’s a completely sealed system free of exposed contacts. And it’s very forgiving, requiring no precise alignment. You simply hold the connector near the back of the watch, where magnets cause it to snap into place automatically.”

This Apple Watch Magnetic Charging Cable is shown below along with a 42mm Apple Watch Edition Series 2 (white ceramic case).

Source: Apple

Posted on

iPhone XR (packaging, 2018, 2020)

In 2020 Apple made a major change to its iPhone 12 packaging when they stopped including Lightning headphones and a wall power “brick” charger in the box at the time of an iPhone purchase. With these items removed, Apple was able to reduce the size of the iPhone box and reduce the extra packaging associated with the headphones and charger. It was announced that the iPhone 12 would ship only with the phone and a USB-C-to-Lightning charging cable.

Lisa Jackson, Apple’s Vice President of Environment, Policy, and Social Initiatives, announced at an October 2020 Apple event, “Customers already have over 700 million Lightning headphones, and many customers have moved to a wireless experience with AirPods, Beats, or other wireless headphones. And there are also over 2 billion Apple power adapters out in the world, and that’s not counting the billions of third-party adapters. So we are removing these items from the iPhone box.”

With the iPhone 12 announcement, I was not at all expecting this packaging change to also affect older, but still manufactured iPhone models. At the time of the iPhone 12 release, Apple was still offering the iPhone XR as a lower-end and less expensive iPhone option. Surprisingly, the iPhone XR packaging was also reduced in size and shipped without the headphones and charger. Also, the cable was switched to a USB-C-to-Lightning, replacing the former USB-to-Lightning option.

While the change may contribute to some environmental benefits, the situation was not universally accepted as positive. Some critics noted that, “The move saves the company money, but some of the environmental benefits could be offset by people buying earbuds and chargers separately” (The Verge). From a practical standpoint, some users—namely enterprise, government, and school districts like mine—had not switched to USB-C when this decision was made. As Apple indicated, it is likely that most users likely already have more than one charger and at least one set of Lightning headphones.

The photos here represent my school district’s iPhone XR upgrade affected mid-stream—where iPhone XR models purchased before October 2020 used “classic” packaging, and devices purchased in late-October/November 2020 unexpectedly used the new packaging without an announcement or warning.

Sources: AppleInsider, The Verge

Posted on

Mac OS 9 9.0.4 box (2000)

Mac OS 9 was Apple’s final version of its “Classic” operating system. This iteration, version 9.0.4, was released April 4, 2000, and its changes included “Improved USB and FireWire support and other bug fixes.”

This specific boxed version is a 10-client license and features iTools, Apple’s first suite of online services that would eventually become iCloud.

The box also mentions that Mac OS 9 introduces “more than 50 new features” and includes “nine Internet power tools.” The tools include:

  1. Sherlock 2
  2. Multiple Users
  3. Voiceprint Password
  4. Keychain
  5. Auto Updating
  6. Encryption
  7. File Sharing over the Internet
  8. AppleScript over TCP/IP
  9. Network Browser

Source: Wikipedia

Posted on

Education Resource CD Winter 2000 (2000)

This Education Resource CD is dated Winter 2000. Its design features a rendition of the glossy 3D tabs on the apple.com website at the time. The toolbox image at the bottom of the CD matched the iTools design. iTools is a precursor to what has become Apple iCloud services.

Posted on

Macintosh Server G3/300 Minitower (1998)

The Macintosh Server G3/300 Minitower was released in 1998 as the final beige tower design by Apple. This G3 Server used a 300 MHz PowerPC 750 G3 processor, a single 4.0 GB SCSI hard drive (with space for a second drive), and a 24x CD-ROM drive.

This minitower also contained a “Whisper personality card” that added audio input and output ports. According to LowEndMac, Apple had planned various “personality cards,” but only audio (“Whisper”), audio/video (“Wings”), and audio/video/DVD playback (“Bordeaux”) were ever produced.

The case design of this minitower includes a removable side panel and two internal tabs that, when released, allow the entire tower to tilt 90 degrees on a hinge allowing easy access to all internal components. Interestingly, the side door panel latch and internal tabs are made from translucent blue-green plastic, a design aesthetic that would soon become the Mac design norm that same year when the original iMac was released.

Ports on this computer include SCSI; ADB (Apple Desktop Bus); Ethernet (10-100); Mac serial and printer ports; Apple Video (DB-15), line-out and microphone 3.5 mm jacks. Three card slots are available: the first is empty, but ready for a high-speed SCSI port; the second slot has a second high-speed ethernet port; and the third slot adds two USB ports.

The exact factory configuration of the server is shown as: 1MB Cache/128MB/2x4GB UW/CD/10-100 ENET. The model is M4405, and the serial number area specifies a production date of May 27, 1998, at 3:30 PM.

Sources: EveryMac, LowEndMac

Posted on

Power Mac G5 (Dual Core, 2.3 GHz, 2005)

The Power Mac G5 tower represented a major design departure from the four previous Mac “pro” tower designs. The Power Mac G5 used an anodized aluminum alloy case design with a removable side panel that replaced the hinged door on previous Mac towers.

The sides of the Power Mac G5 were solid aluminum with a light gray Apple logo printed on center. The front and back used a pattern of aluminum perforations as design elements, structure, and as part of the ventilation for the internal systems.

This model is a Power Mac G5 Dual Core running at 2.3 GHz. The same design was available in a G5 Dual Core (2.0 GHz) and a G5 Quad Core (2.5 GHz) variation, with all models using 970MP G5 processors with two independent cores on a single chip. This tower included 512 MB or 1 GB RAM (SDRAM), a 250 GB (Serial ATA) hard drive, a 16x dual-layer SuperDrive, and a NVIDIA GeForce 6600 video card.

The front of the tower included a single optical drive, the power button, and three ports: one 3.5 mm headphone jack, one USB port, and a FireWire 400 port.

The back of the tower included four slots. Slot 1 includes two DVI ports (one single-link DVI and one dual-link DVI port), while slots 2–4 are unused. Rear ports include two independent Gigabit Ethernet ports, one FireWire 400 port, one FireWire 800 port, optical digital audio in/out ports, a 3.5 mm line-out audio jack, a 3.5 mm line-in audio jack, and three USB 2.0 ports.

Internally, the tower supports AirPort Extreme (802.11g) and Bluetooth 2.0 wireless protocols. Everymac reports that the inside of Power Mac G5 models were divided into “four different thermal zones with nine computer-controlled fans for optimum cooling.” Also, this Power Mac G5 has two internal hard drives.

The case design with its front and back aluminum perforations and handles is, indeed, reminiscent of a cheese grater—albeit a beautiful one.

Source: Everymac

Posted on

Power Mac G4 (1.25 GHz, “mirrored drive doors,” 2003)

The Power Macintosh G4/1.25 GHz “Mirrored Drive Doors” tower used a 1.25 GHz PowerPC 7455 G4 processor, 256 MB RAM, an 80 GB hard drive, a 12X DVD-ROM/CD-RW “Combo” drive, and allowed wireless using an optional AirPort (802.11b) card. This model was released along with new Power Macintosh G5 models to provide a lower-cost alternative for users who did not need the power of the G5 and still wanted to boot with the MacOS 9 operating system.

While similar to the previous “Quicksilver” model, the front of this tower retains the silver opaque color, but adds a mirror-finished plate over the two available optical drive doors in the center. Although two drive spaces are available, this example only uses one “Combo” (CD/DVD reader/writer) drive in the top position. The prominent drive doors also include the power button at the top-center and an “interrupt” button off to the right. A single speaker is placed above the doors. Four conspicuous ventilation holes span the bottom of the front of this tower.

The back of the tower was flipped compared to previous similar tower designs (G3 blue and white, G4 graphite, and G4 Quicksilver), in that the expansion slots are placed at the top. This tower has spaces for five slots, but only uses slot 1 (at the bottom) to house a VGA port and ADC (proprietary Apple Display Connector) port; slots 2–5 are unused. Ports are included below with two USB, two FireWire (400), one ethernet, a space for a modem port, and side-by-side microphone (line-in)/speaker (audio-out) 3.5 mm jacks. A dedicated Apple speaker port is included to allow Apple’s crystal-clear spherical speakers to be used.

The right side of the tower included a latch with a circular rubberized grip that allowed the entire side of the tower to be opened on a hinge, revealing and providing relatively easy access to all internal components. Plug-in slots (such as video, memory, and wireless) were attached to the hinged side, while components such as drives and fans remained attached to the internal metal frame of the tower.

A design concept worth noting in this tower is its two-layer round-hole pattern on the back. The internal layer features smaller, closely spaced holes in silver metal, while the larger outer holes are spaced further apart in light-silver plastic. The concept is similar to the somewhat-maligned “cheese grater” design used in the 2019 Mac Pro tower. The 2019 Mac Pro uses a “machined spherical array” of ventilation holes in a distinctive design—”The lattice pattern on the Mac Pro is based on a naturally occurring phenomenon in molecular crystal structures.” To be clear, the 2019 design is a single piece of machined metal—not two separate layers—but the designs are related visually. In both the 2003 and 2019 towers, the holes are used simultaneously as design, structure, and ventilation.

Source: Everymac, Apple
